    12500RPM Brushed Permanent Magnet DC Motor For Coffee Machine Grinder

    Ask Lasest Price
    Brand Name : SECORE
    Model Number : DC31
    Certification : CE ROHS
    Price : Negotiated The Price
    Payment Terms : T/T, D/A
    Supply Ability : 100000pcs per month
    Delivery Time : 10-12 working days
    • Product Details
    • Company Profile

    12500RPM Brushed Permanent Magnet DC Motor For Coffee Machine Grinder

    12500RPM Coffee Machine Brushed Permanet Magnet DC Motor For Grinder


    Key Specifications/Special Features:

    Model: DC31
    Voltage:230V
    Torque:95mN.m
    Power:207W
    Speed:12500RPM
    Introduction:Small Size;Low Noise;High Speed

    HV permanent magnet DC motor applies for hand blender, meat grinder, meat mincer, mixer, food processor, power tools, smart household appliances


    MODELSPECVOLTAGENO LOADAT MAXIMUM EFFICIENCY
    ABCOperating
    range
    RATEDSPEEDCURRENTPOWERSPEEDCURRENTOUTPUTTORQUE
    r/minAWr/minAWm.Nm
    DC313054.59820100V-240V230V150000.1931125001.120790
    DC313559.510922100V-240V230V145000.2136115800.813475.2


    12500RPM Brushed Permanent Magnet DC Motor For Coffee Machine Grinder


    12500RPM Brushed Permanent Magnet DC Motor For Coffee Machine Grinder


    The advantages and disadvantages of brushed motors:


    Advantages:

    • Easy to control and therefore have the ability to control many motors from a single controller
    • High torque at low revels
    • Inexpensive

    Disadvantages:

    • They are less efficient than brushless motors (75-80% compared to 85-90% for brushless motors).
    • Their service lifespan is short because the brushes, due to regular friction, wear out more quickly over time (between 1,000 and 10,000 operating hours depending on the frequency of use, power, speed, vibration, etc.)
    • The arc of the brushes and collector can generate electromagnetic noise that high noise.
    • Similarly, the risk of sparks due to friction makes using this type of motor in explosive environments undesirable.
    • The speed is generally limited due to the heating of the brushes.
    • Brushes made of graphite generate dust that can damage other devices, such as optical devices.
    • They need to be lubricated, which makes it impossible to use them in vacuum cleaners.

    12500RPM Brushed Permanent Magnet DC Motor For Coffee Machine Grinder


    FAQ


    Q1. What kind of motors you can provide?

    A: Full range of precision gearbox, diameters 6mm,8mm,10mm,12mm,13mm,16mm,20mm,22mm,24mm,28mm,32mm,36mm,37mm,42mm,48mm, output speed 5-3000rpm,reduction ratio 5-1500, output torque 1g.cm to 500kg.cm


    Q2. Can you send me a price list?

    A: For all of our motors, they are customized based on different requirement as per torque, lifetime, noise, voltage, and shaft etc. The price also varies according to annual quantity. So it's really difficult for us to provide a price list. If you may, please share your expected performance and specific requirement for us better to provide a solution and closest offer.


    Q3. What's the lead time for regular order?
    A: For mass orders, the standard lead time is 25-40 days and LT can be shorter or longer based on different model, period and quantity.


    Q4. Is it possible for you to develop new motors if we can provide tooling cost?
    A: Yes. Please kindly share the detailed requirements like performance, size, annual quantity, target price etc. Then we'll make our evaluation to see if we can arrange or not.


    Q5. Can I get some samples?
    A: Yes, we are glad to offer samples for testing before the initial order. We’re afraid we don’t make sample for personal use or replacement.
