Pernanent Magnet 100W 150W Compact BLDC Motor Lower EMI High Speed

Ask Lasest Price
Brand Name :	SECORE
Model Number :	BLS42-50W
Certification :	CE ROHS
Price :	Negotiated The Price
Payment Terms :	T/T, D/A
Supply Ability :	7000pcs per month
Delivery Time :	7-10 working days
MOQ :	1 PC

Add to Cart

Product Details
Company Profile

Pernanent Magnet 100W 150W Compact BLDC Motor Lower EMI High Speed

30W 50W 75W 100W 150W Compact BLDC Motor, High Precision Control Brushless AGV Motor

Secore Motor specializes in the production and sales of various DC brush & brushless motors, provides one-to-one customer service, and accepts customization of motors with special parameters. Welcome to inquire.

Feature:

1. free maintenance
2. small compact size, light weight
3. low power consumption
4. high efficiency, high C/P, low heat losing
5. high speed and performance
6. lower EMI, lower emission
7. reversible direction, convenient speed adjustment
8. smart controlling

30W

Model number	Voltage V	Power W	Rated speed rpm	Rated current A	Rated torque N.m	No-load speed rpm	No-load current A	Peak Torque N.m
电机型号	电压 V	功率 W	额定转速 rpm	额定电流 A	额定转矩 N.m	空载转速 rpm	空载电流 A	最大转矩 N.m
BLS57-30W-1230	12	30	3000	3.14	0.1	3300	<0.6A	0.29
BLS57-30W-2430	24	30	3000	1.57	0.1	3300	<0.4A	0.29
BLS57-30W-3630	36	30	3000	1.04	0.1	3300	<0.3A	0.29
BLS57-30W-31030	310	30	3000	0.13	0.1	3300	<0.2A	0.29

50W

Model number	Voltage V	Power W	Rated speed rpm	Rated current A	Rated torque N.m	No-load speed rpm	No-load current A	Peak Torque N.m
电机型号	电压 V	功率 W	额定转速 rpm	额定电流 A	额定转矩 N.m	空载转速 rpm	空载电流 A	最大转矩 N.m
BLS57-50W-1230	12	50	3000	5.21	0.16	3300	<0.8A	0.48
BLS57-50W-2430	24	50	3000	2.6	0.16	3300	<0.4A	0.48
BLS57-50W-3630	36	50	3000	1.74	0.16	3300	<0.3A	0.48
BLS57-50W-31030	310	50	3000	0.2	0.16	3300	<0.2A	0.48

75W

Model number	Voltage V	Power W	Rated speed rpm	Rated current A	Rated torque N.m	No-load speed rpm	No-load current A	Peak Torque N.m
电机型号	电压 ( V )	功率 ( W )	额定转速 ( rpm)	额定电流( A )	额定转矩( N.m)	空载转速( rpm)	空载电流 ( A )	最大转矩 (N.m)
BLS57-75W-1230	12	75	3000	7.81	0.24	3300	<1.0A	0.72
BLS57-75W-2430	24	75	3000	3.91	0.24	3300	<0.7A	0.72
BLS57-75W-3630	36	75	3000	2.6	0.24	3300	<0.5A	0.72
BLS57-75W-4830	48	75	3000	1.95	0.24	3300	<0.4A	0.72
BLS57-75W-31030	310	75	3000	0.3	0.24	3300	<0.3A	0.72

150W

Model number	Voltage V	Power W	Rated speed rpm	Rated current A	Rated torque N.m	No-load speed rpm	No-load current A	Peak Torque N.m
电机型号	电压 V	功率 W	额定转速 rpm	额定电流 A	额定转矩 N.m	空载转速 rpm	空载电流 A	最大转矩 N.m
BLS57-150W-1230	12	150	3000	15.63	0.48	3300	<1.5A	1.43
BLS57-150W-2430	24	150	3000	7.81	0.48	3300	<1.0A	1.43
BLS57-150W-3630	36	150	3000	5.21	0.48	3300	<0.8A	1.43
BLS57-150W-4830	48	150	3000	3.91	0.48	3300	<0.6A	1.43
BLS57-150W-31030	310	150	3000	0.6	0.48	3300	<0.4A	1.43

TO BE TAILORED

* Expected voltage types

* Configurable shaft length and second shaft end

* Extended temperature range

* Modified shaft dimensions and pinion configurations such as flats, gears, pulleys and eccenter

* Customization for high speed and or high load applications

* Customization for motors with increased electrical or mechanical tolerance requirement

Secore Technology is a professional manufacturer which makes BDC motor, BLDC motor with Gearbox, planetary gearhead, worm gearhead, helical gearbox, customize according to expectation.
